Name: 12-10 AWG Non-Insulated Ring Terminals - #8 Stud Tin-Plated Copper - 100 or 1000 Pack - Made in USA
SKU: WYA76108
Availability: InStock

12-10 AWG Non-Insulated Ring Terminals – #8 Stud Tin-Plated Copper – 100 or 1000 Pack – Made in USA

$6.29 $10.49

These 1210 AWG non-insulated ring terminals are built to deliver secure, high-conductivity crimp connections in demanding automotive, fleet, and industrial wiring jobs. Fabricated from annealed copper (Alloy 110) and electro tin-plated for corrosion protec

Pack Size:

Security Policy (Protecting Your Data, Ensuring Your Safety)
Delivery Policy (Free shipping on orders over $30)
Return Policy (60 day easy Return)

SKU: WYA76108 Category: Wire Connectors & Terminals

Description Reviews (0)

These 1210 AWG non-insulated ring terminals are built to deliver secure, high-conductivity crimp connections in demanding automotive, fleet, and industrial wiring jobs. Fabricated from annealed copper (Alloy 110) and electro tin-plated for corrosion protection, they feature brazed barrel seams and V-groove serrations that ensure maximum mechanical strength and current flow after crimping.

Specifications & Features

Wire Gauge: 1210 AWG
Stud Size: #8
Terminal Type: Non-insulated ring terminal
Material: Pure copper (Alloy 110), annealed
Plating: Electro tin-plated
Termination Type: Crimp
Seam Type: Brazed barrel
Serration Design: V-groove serrations increase pull-out resistance and conductivity
Voltage Rating: 600 Volts
Temperature Rating: Up to 230F (110C)
Certifications: cULus listed
Markings: Terminal size is clearly printed for easy identification
Specification Compliance: MIL-T-10727C Type 1, ASTM B 545 B (.0001″.00025″ plating thickness)
Made in USA
