Siemens Sitrans P 7Mf4033-1Ea10-2Nc1 Pressure Transmitter 4-20Ma Hart Ip65
Siemens
Sitrans P
Ped:Sep
Transmitter For Pressure
7Mf4033-1Ea10-2Nc1
Fab.-nr.: N1-a608-9150706
Vh: Dc 10.5-45V (Non Is) 4-20 Ma Hart
Mat:
Connec. Diaphr Filling
1.4404 1.4404 Silicone Oil
Measuring Span: 0.63 – 63 Bar
Overrange Limits: -1 100 Bar
Type Of Protection Ip65
(Xp/Dip) Or (Intrinsically Save)
Cl I Zn 0/1 Aex Ia Iic T4…T6 (Fm)
Ex Ia Iic T4…T6 (Csa Cert.2000.1153651)
Cl I, Div 1, Gp Abcd T4T6; Cl Ii, Div 1, Gp Efg; Cl Iii
Vi 30V; Ii 100Ma; Pi 0.75W
Ci 6 Nf; Li 0.4 Mh
Cl I Div 2 Gp Abcd T4…T6
Cl Ii Div 2 Gp Fg; Cl Iii
Vmax = 30 V
Ta = T4: -4085C; T6: -4060C
Encl Type 4X, Seal Not Required
Fw: 0011.03.06
Hw: 02.05.01
Use Supply Wires Suitable For 20C Above Ambient Temperature
Ex 685
A5E00256870
A5E00375500
C73451-a407-b7
Es: 07
C41
981720
W1/24/10
Made In France
Weight: 1.540 Kg
