HP Rating @ 540RPM: 35HP,
German Series: AW21/W2300.
Alternative to = GARDLOC PTO Shaft – (Lz) Length: 560mm, 1 3/8” x 6 Spline Q.R. to 1 3/8” x 6 Spline Q.R.128678https://75025d40dd58ab042ef4-3509ef0b9210fbf84c18b36ced24de7a.ssl.cf3.rackcdn.com/imagelibrary_sml/128678_pic1.jpgGARDLOCHP Rating @ 540RPM: 30HP, Italian Series: AB3/A3.GARDLOC PTO Shaft – (Lz) Length: 560mm, 1 3/8” x 6 Spline Q.R. to 1 3/8” x 6 Spline Q.R.128715https://75025d40dd58ab042ef4-3509ef0b9210fbf84c18b36ced24de7a.ssl.cf3.rackcdn.com/imagelibrary_sml/128715_pic1.jpgGARDLOCHP Rating @ 540RPM: 35HP, German Series: AW21/W2300.128678, 128715
Brand = Sparex
German Series = AW21/W2300
Grease Coupler = Central Grease Nipple
HP Rating @ 540RPM = 35
HP Rating Range @ 540RPM = up to 54
Implement End = 1 3/8” x 6 Spline Q.R.
Kilowatt Power Rating @ 540RPM = 26
Lz Length (mm) = 560
PTO Series = AW21/W2300
Related products = PTO Guard – GARDLOC, (Lz) Length: 950mm, Size: Small Guard163810https://75025d40dd58ab042ef4-3509ef0b9210fbf84c18b36ced24de7a.ssl.cf3.rackcdn.com/imagelibrary_sml/163810_pic1.jpgGARDLOCItalian Series: A1, A2, A3, A4, German Series: AW10/W2100, AW11/W1, AW20/W2200, AW21/W2300 OV/1.Supplied with: 34.4mm x 1, 40.4mm x 2, 41.5mm x 2, 46.4mm x 1, 47.4mm x 1, 50.5mm x 2, 53.4mm x 1 Rings163810
Tariff Code = 8483908990
Torque (Nm) = 460
Torque Range (Nm) = 335 – 1240Nm
Total Closed Length (mm) = 775
Tractor End = 1 3/8” x 6 Spline Q.R.
Tube Profile = Lemon
Tube Ref = 0v/1
Universal Joint Dimensions = 27 x 74.5mm

Suitable For Information
This product is not associated with any particular make or model

OEM Fitment Information
This product is not associated with any particular OEM part number
