Red, high temperature, fast cure, air dry, polyurethane varnish. Excellent insulator coating for electrical/electronic parts.
| Property | Specification |
| Product Name | SYNTHITE ER-41 |
| Type | Air-Drying Polyurethane Varnish |
| Color | Red |
| Temperature Class | Class F 155C |
| Application Methods | Dip, Brush, Spray |
| Curing Type | Room Temperature Cure |
| Drying Time | Set to Touch: 10 minutes Tack-Free: 30 minutes |
| Film Thickness | 1.5 2.5 mils per side |
| Dielectric Strength | Dry: 1,800 V/mil Wet: 1,200 V/mil |
| Chemical Resistance | Excellent (Water, Acid, Alkali, Salt Water, Oil) |
| Adhesion | Excellent |
| Abrasion Resistance | Superior |
| VOC Content | 4.4 lbs/gal (47%) |
| Thinner | T-200X |
| Packaging | 1 Gallon Can |
| Weight | Approximately 10 lbs |
| Dimensions (WHD) | 7.00″ 7.00″ 8.00″ (177.8 mm 177.8 mm 203.2 mm) |
| Shelf Life | 1 year at 70F (21C) |
| Manufacturer | John C. Dolph Company |
